Power Amplifier
Power Output into 8 Ohm: 80 Wrms per Channel, Both Channels Driven, Nominal (THD+N <1 %)
Power Output into 4 Ohm: 130 Wrms per Channel, Both Channels Driven, Nominal (THD+N <1 %)
THD+N: <0.02 % (1 kHz, 2 channels, 1 W @ 8 Ohms, A-Weighted)
Amplifier Type: Class AB
Gain: 29 dB
Channel Matching: <0.5 dB
Signal to Noise Ratio: >80 dBa 1 W/ 8 R, >98 dBa 75 W/ 8 R
Channel Separation: >75 dB @10 kHz
Frequency Response: 5 Hz to 50 kHz (-3 dB)
Pre-Amplifier*
Volume Channel Matching: <0.25 dB
THD+N: 0.002 % (1 kHz, 2 Vrms, A-Weighted)
Channel Separation: >102 dB (1 kHz, 100 mV)
Signal to Noise Ratio: >104 dB (unweighted)
RIAA (Phono): 47 kΩ/ 56 pf loading; gain settings suitable for 12 mV, 6 mV, 3 mV output
cartridges
*measured at the Pre-Out
BluOS
(Streaming Amp ONLY)
Audio Formats MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS
Hi-Resolution Audio Formats MQA, FLAC, WAV, AIFF, Supports converted DSD playback via the BluOS desktop app (only)
Sampling Rate Up to 32 bit / 192 kHz
Supported Operating Systems. Plays music from network shares on the following desktop operating
systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows
Operating Systems and Mac OS X versions
Mobile Device Support BluOS App – free on Android & iOS, available within Google Play & Apple App Store
Mobile Device Control BluOS application can control inputs, volume and configure BluOS related settings
Supported Cloud Services Amazon Alexa, Amazon Music, Spotify, TIDAL, Deezer, Qobuz, HDTracks,
HighResAudio, Murfie, JUKE, Napster, Slacker Radio, KKBox, Bugs
Free Internet Radio TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise
Control Integrations Crestron, Control4 (OS 3), Control4 (2.9.1), RTI, URC, Push, Lutron, ELAN, iPort
Bluetooth
Bluetooth: A2DP Audio profile
Bluetooth Codecs: SBC, aptX & AAC
Bluetooth Range: 15 m (typical, clear line of sight)
Digital Inputs
Digital Coax Input: up to 24 bit/ 192 kHz PCM
Digital Optical Input: up to 24 bit/ 96 kHz PCM
DAC
Format Support: PCM
Sampling Rate: up to 192 kHz/ 24 bit
THD+N: 0.001 % (1 kHz, 2 Vrms at Pre-Out)
Signal to Noise Ratio: 106 dB (A-Weighted)
Other
IR Receiver 5V – 14V, mono 3.5mm jack plug, any polarity
12V Trigger Input 5V-14V, 3.5mm jack dual polarity
12v Trigger Output 3.5mm jack Pass through from input only
Construction Formed plated steel and bespoke machine anodised aluminium front panel
Dimensions (H x W x D) 76 x 432 x 373 mm (Inc Feet, Connectors & Buttons) 3 x 17 x 1411/16 Inches
Streaming Amplifier Weight 10.48 Kg 23 lb
Integrated Amplifier Weight 10.37 Kg 22 lb 14 oz
Mains input 100-130 VAC 50/60 Hz
(Auto Selecting) 210-240 VAC 50/60 Hz
(Operational down to 85 VAC with reduced outputpower)
Power consumption Full Power: 400 W max Standby: <0.5 W Network Standby: 6 W
